The CVEDIA Box

Balanced performance for a variety of machine learning applications.

Ask us about hardware

Powerful Performance

The CVEDIA Box is a custom-built hardware package prepared for use with CVEDIA models. It provides pre-installed, seamless integration with your CVEDIA machine learning model. Simply plug it into your device and go.

The NVIDIA Jetson AGX Xavier was chosen as a base for the CVEDIA Box due to its balanced capability profile while retaining good processing performance. It’s appropriate for a wide number of applications including edge deployment, network-heavy applications, and prototyping.

Ready to Deploy

Maintained

Includes ongoing software maintenance

Fast

Designed for edge deployment

Rugged

Rugged construction built for outdoor applications

Seamless

Seamless deployment - plug and go

  • Specs

    Type

    Box PC with AVerCooler WavieFin passive cooling system

    NVIDIA GPU SoC Module Compatibility

    NVIDIA® Jetson AGX Xavier™ 16GB module

    Networking

    2x GbE (RJ-45)

    Display Output

    1x HDMI type A, maximum resolution: 3840×2160 at 60Hz

    Temperature

    Operating Temperature: -10°C~60°C (MODE_30W_ALL, No-Air-Flow)

    Storage Temperature: -40°C ~ 85°C

    Relative Humidity: 40 °C @ 95%, Non-Condensing

    USB

    1x USB 2.0 Micro-B for BSP installation only

    2x USB 3.0 Type-A (USB3.2 Gen1 x1)

    Storage

    32GB eMMC 5.1

    RS-485

    1x RS-485

    CAN Bus

    1x CAN bus with transceiver

    GPIO Expansion

    40 pins: 1x UART, 2x I2C, 1x CAN (W/O transceiver), 5x GPIO

    User Expansion

    1x M.2 Key E 2230 for Wi-Fi module (PCIe Gen4x 1)

    1x M.2 Key M 2280 for NVMe (PCIe Gen4x 4)

    2x M.2 Key M 2280 (PCIe Gen2 x2) or 4x mPCIe Gen2 x1

    Input Power

    12V/5A

    Buttons

    Power and Recovery (Each button has a RGB tri-color LED)

    RTC Battery

    Support RTC battery and Battery Life Monitoring by MCU

    Chassis Dimension/Weight

    W:196mm x L:242mm x H:60mm

    7.72″ x 9.53″ x 2.36″, with mounting ears W:226mm, 8.9”

    Weight: 2.5Kg

    Certifications

    CE, FCC
